S9KEAZN16AMLCR Microcontroller MCU 32-Bit 40MHz ARM Cortex-M0+ Kinetis KEA Microcontroller

S9KEAZN16AMLCR Microcontroller MCU 32-Bit 40MHz ARM Cortex-M0+ Kinetis KEA Microcontroller

Product Description Of S9KEAZN16AMLCR
S9KEAZN16AMLCR is 32-Bit 40MHz ARM Cortex-M0+ Kinetis KEA Microcontroller.
Kinetis® EA series of 32-bit Arm® Cortex® MCUs are targeted for a wide range of automotive and industrial applications requiring the highest level of quality and longevity support.

Specifications Of S9KEAZN16AMLCR

Features Of S9KEAZN16AMLCR
Operating characteristics
• Voltage range: 2.7 to 5.5 V
• Flash write voltage range: 2.7 to 5.5 V
• Temperature range (ambient): -40 to 125°C
Performance
• Up to 40 MHz Arm® Cortex-M0+ core and up to 20 MHz bus clock
• Single cycle 32-bit x 32-bit multiplier
• Single cycle I/O access port
Memories and memory interfaces
• Up to 64 KB flash
• Up to 256 B EEPROM
• Up to 4 KB RAM
Clocks
• Oscillator (OSC) - supports 32.768 kHz crystal or 4 MHz to 20 MHz crystal or ceramic resonator; choice of low power or high gain oscillators
• Internal clock source (ICS) - internal FLL with internal or external reference, 31.25 kHz pre-trimmed internal reference for 40 MHz system and core clock.
• Internal 1 kHz low-power oscillator (LPO)
System peripherals
• Power management module (PMC) with three power modes: Run, Wait, Stop
• Low-voltage detection (LVD) with reset or interrupt, selectable trip points
• Watchdog with independent clock source (WDOG)
• Programmable cyclic redundancy check module (CRC)
• Serial wire debug interface (SWD)
• Bit manipulation engine (BME)
Security and integrity modules
• 64-bit unique identification (ID) number per chip
Human-machine interface
• Up to 57 general-purpose input/output (GPIO)
• Two up to 8-bit keyboard interrupt modules (KBI)
• External interrupt (IRQ)
Analog modules
• One up to 16-channel 12-bit SAR ADC, operation in Stop mode, optional hardware trigger (ADC)
• Two analog comparators containing a 6-bit DAC and programmable reference input (ACMP)
Timers
• One 6-channel FlexTimer/PWM (FTM)
• Two 2-channel FlexTimer/PWM (FTM)
• One 2-channel periodic interrupt timer (PIT)
• One real-time clock (RTC)
Communication interfaces
• Two SPI modules (SPI)
• Up to three UART modules (UART)
• One I2C module (I2C)

Applications Of S9KEAZN16AMLCR
Automotive
Diesel Engine Management
Electric Pumps
Motorcycle Engine Control Unit (ECU) and Small Engine Control
Industrial
3-Phase AC Induction Motor
Brushless DC Motor (BLDC) Control
Motion Control and Robotics
Motor Drives
Permanent Magnet Synchronous Motor (PMSM)
