ADA4891-4WARUZ Integrated Circuit Chip Low Cost CMOS High Speed Rail-To-Rail Amplifier

ADA4891-4WARUZ Integrated Circuit Chip Low Cost CMOS High Speed Rail-To-Rail Amplifier

Product Description Of ADA4891-4WARUZ
ADA4891-4WARUZ is CMOS, high speed amplifiers that offer high performance at a low cost. The amplifiers feature true single-supply capability, with an input voltage range that extends 300 mV below the negative rail.

Product Attributes Of ADA4891-4WARUZ

Features Of ADA4891-4WARUZ
High speed and fast settling
−3 dB bandwidth: 220 MHz (G = +1)
Slew rate: 170 V/μs
Settling time to 0.1%: 28 ns
Video specifications (G = +2, RL = 150 Ω)
0.1 dB gain flatness: 25 MHz
Differential gain error: 0.05%
Differential phase error: 0.25°
Single-supply operation
Wide supply range: 2.7 V to 5.5 V
Output swings to within 50 mV of supply rails
Low distortion: 79 dBc SFDR at 1 MHz
Linear output current: 125 mA at −40 dBc
Low power:
4.4 mA per amplifier

Applications Of ADA4891-4WARUZ
Imaging
Consumer video
Active filters
Coaxial cable drivers
Clock buffers
Photodiode preamp
Contact image sensor and buffers
